A water pump’s wattage ranges from 250 watts for a small 0.5 HP surface pump to over 2,000 watts for a 2 HP submersible well pump. The exact draw depends on the pump type, motor horsepower, head pressure (how high it pushes water), and whether it is single-phase or three-phase. This guide covers every common pump type with the real-world wattage — not just the label rating — so you can size your solar system, battery backup, or generator correctly.
Water Pump Wattage by Type and HP
| Pump Type | HP | Running Watts | Startup Surge |
|---|---|---|---|
| Surface jet pump (shallow well) | 0.5 HP | 250 – 400W | 750 – 1,200W |
| Surface jet pump | 1 HP | 500 – 750W | 1,500 – 2,250W |
| Submersible well pump | 0.5 HP | 370 – 500W | 1,000 – 1,500W |
| Submersible well pump | 0.75 HP | 550 – 750W | 1,650 – 2,250W |
| Submersible well pump | 1 HP | 750 – 1,000W | 2,250 – 3,000W |
| Submersible well pump | 1.5 HP | 1,100 – 1,500W | 3,300 – 4,500W |
| Submersible well pump | 2 HP | 1,500 – 2,000W | 4,500 – 6,000W |
| Booster pump (pressure) | 0.5 – 1 HP | 370 – 750W | 1,000 – 2,250W |
| Sump pump | 0.33 HP | 250 – 400W | 750 – 1,200W |
| Sump pump | 0.5 HP | 400 – 600W | 1,200 – 1,800W |
| Circulation pump (HVAC) | 0.1 – 0.25 HP | 60 – 200W | 150 – 400W |
| 12V DC water pump (RV/marine) | N/A | 30 – 60W | 60 – 120W |
The HP to Watts Formula
One mechanical horsepower equals 746 watts. A 1 HP pump motor theoretically draws 746W, but real-world consumption is higher because electric motors are not 100 percent efficient. Most pump motors run at 60 to 80 percent efficiency, meaning a 1 HP pump actually draws 746 ÷ 0.70 = roughly 1,066 watts from the wall. The table above reflects real-world measured draws, not theoretical HP conversions.
The startup surge is the critical number for sizing inverters and generators. Every pump has an induction motor that draws 3 to 4 times its running watts for 1 to 3 seconds at startup. A 1 HP submersible pump running at 750W surges to 2,250W — your inverter must handle this peak or it will trip. Our inverter sizing guide explains how to account for motor surge, and our Battery Charge & Discharge Calculator sizes the inverter automatically when you enter the pump as your largest motor load.
How Much Energy Does a Water Pump Use Per Day?
A water pump does not run continuously — it cycles on and off based on demand. A typical household well pump runs 1 to 3 hours per day total. A 1 HP submersible running 2 hours daily consumes 750W × 2 hours = 1,500 Wh (1.5 kWh) per day. A 0.5 HP surface pump running 1.5 hours uses 400W × 1.5 = 600 Wh (0.6 kWh) per day. A sump pump in a dry season may run only 15 minutes per day (100 Wh), while during heavy rain it may run 4 to 6 hours (2,400 Wh).
To find your pump’s actual daily consumption, check your pressure tank’s cycle rate — how often the pump kicks in and for how long each cycle. Alternatively, use a watt meter (Kill A Watt) for 24 hours to measure directly. Look up your pump’s estimated wattage in our Appliance Wattage Database.
Well Pump vs Surface Pump: Which Uses More Power?
Submersible well pumps always use more power than surface pumps at the same HP rating because they work against gravity — pushing water up from 50 to 300 feet underground. A 1 HP surface pump (jet pump) drawing water from 25 feet draws about 500 to 750 watts. A 1 HP submersible well pump lifting water from 150 feet draws 750 to 1,000 watts. The deeper the well, the harder the pump works and the more watts it consumes. If you are sizing solar or battery backup for a well pump, knowing the well depth is essential — it directly affects the wattage, the inverter size, and the daily energy consumption. Ask your well driller or check the pump nameplate in the well head for the exact HP and rated current.
Sizing Solar Panels for a Water Pump
A 1 HP well pump using 1,500 Wh per day in a 5-sun-hour location needs: 1,500 ÷ 5 ÷ 0.82 (system derating) = 366W of solar panels. With a 25 percent margin: 457W — a single 500W panel or two 250W panels. For a 0.5 HP pump using 600 Wh daily: 600 ÷ 5 ÷ 0.82 × 1.25 = 183W — one 200W panel. Our Solar System Calculator sizes the complete system including the pump and all other loads.
Running a Water Pump on Battery Backup
A water pump is one of the most critical loads during a power outage — no pump means no water from a well. A 0.5 HP pump drawing 400W needs a battery that handles both the running load and the 1,200W startup surge. A 100Ah 12V LiFePO4 battery runs a 0.5 HP pump for about 2.5 hours of actual pumping time (1,026 usable Wh ÷ 400W). For 8 hours of intermittent pumping (pump runs 20 minutes every 2 hours = 1.3 hours actual runtime), a single 100Ah battery is sufficient. A 1 HP pump at 750W needs a 200Ah battery for similar coverage. Size your exact backup in the Battery Backup Calculator.
The startup surge is the challenge: a 0.5 HP pump surges to 1,200W, requiring at least a 1.5 kVA inverter. A 1 HP pump surges to 2,250W, requiring a 3 kVA inverter. Consider a soft starter to reduce the surge by 60 to 70 percent — this can let you use a smaller, cheaper inverter.
